Commissioning Of A State Of The Art Metal Coating Line At M/S Nam Kim Joint Stock Company, Vietnam
August 26, 2016
Esmech Equipment Pvt. Ltd; a Joint Venture Subsidiary of SMS Group commissioned their Sophisticated GI / GL Metal Coating Line at Nam Kim; a Joint Stock Company in Vietnam. The line is installed in Binh Doung Province in South Vietnam for the production of ‘ High-End ‘ quality products.
The first coil processed on the plant on August 26th this year was a Prime Quality Coil witnessed by Namkim Chairman Mr. Quang.
Chairman Mr. Quang, the Nam Kim team and Esmech team with the First Coil
Brief Line Specifications:
Strip Width : 700 – 1250 mm
Strip Thickness : 0.30 mm to 2.0 mm
Coil Weight : 27 MT maximum
Coating : Galvanising ( Zn )
Aluminium – Zinc ( Al-Zn )
Line Speed : 180 mpm (max) – Process speed
250 mpm (max) Entry & Exit over speed.
Furnace Capacity : 52 MT / Hr.
Quality : Full Hand, CQ, DQ, DDQ
Line Capacity : 350,000 TPA
The Special features in the line :
Furnace: SMS – Drever NOX, with inverted ‘U’ vertical Non-Ox section,
Horizontal Radiant tube Heating / Soaking sections, High Pressure Jet Coolers from Drever, Belgium and elaborate calm section.
Pots:Ajax Tocco USA Ceramic Dual Pot System for Zn and Al-Zn with Pre-melt
Air Knife:Esmech “V Jet” Air wiping coat control system.
eMASS: Magnetic Strip Stabilization System from EMG, Germany.
eBAC: Auto Baffle Control System from EMG, Germany.
After Cooling: Esmech High Performance Dynamic Air Cooling Pendants in CAG Section.
Skin Pass & Tension Levelling: Esmech 4 High Skin Pass Mill with ± ve Roll bending & Tension Levller.
Passivation & Protection : Esmech Vertical Coaters for passivation and Organic Coating with AJAX Tocco USA Induction Drying and Cooling System.
Oiling: Electro – static oiler by REVARINI Castoldi & C.S.R.L.; Italy.
Strip Jointer: Auto strip aligning and Limited Over lap welder from Kriton.
Esmech have already supplied a combination GI / GL Metal Coating Line to Nam Kim which is in operation since 2015 and also have one more Metal Coating line under production, scheduled to be commissioned in 2017 in the same plant.
With the commissioning of this line, Nam Kim will have a Coating capacity of 1 Million Tonnes per year.
